Concrete Drilling Range(mm) | Rated Voltage(v) | Rated Frequency(Hz) |
Rated Input Power(w) |
No-load Speed(rpm) | Cable length(m) | Borehole Depth(mm) |
Net/Gross Weight(Kgs) |
Packing Size(cm) |
|---|---|---|---|---|---|---|---|---|---|
| OND-925B | ~10”(~250) | 110/220~ | 50-60 | 4350 | 506 | 3.5 | 600 | 19/22 | 104*38*24 |
| OND-925BE | ~10”(~250) | 110/220~ | 50-60 | 4350 | 100-506 | 3.5 | 600 | 19/22 | 104*38*24 |
| OND-925/2B | ~10”(~250) | 110/220~ | 50-60 | 4350 | 595/940 | 3.5 | 600 | 19/22 | 104*38*24 |
| OND-925/2BE | ~10”(~250) | 110/220~ | 50-60 | 4350 | 100-595/940 | 3.5 | 600 | 19/22 | 104*38*24 |
| OND-930B | ~12”(~300) | 110/220~ | 50-60 | 4650 | 406 | 3.5 | 600 | 20/23 | 104*38*24 |
| OND-930BE | ~12”(~300) | 110/220~ | 50-60 | 4650 | 100-406 | 3.5 | 600 | 20/23 | 104*38*24 |
| OND-930/2B | ~12”(~300) | 110/220~ | 50-60 | 4650 | 410/640 | 3.5 | 600 | 20/23 | 104*38*24 |
| OND-930/2BE | ~12”(~300) | 110/220~ | 50-60 | 4650 | 100-410/640 | 3.5 | 600 | 20/23 | 104*38*24 |
| OND-935B | ~14”(~350) | 110/220~ | 50-60 | 4880 | 335 | 3.5 | 600 | 21/24 | 104*38*24 |
| OND-935BE | ~14”(~350) | 110/220~ | 50-60 | 4880 | 100-335 | 3.5 | 600 | 21/24 | 104*38*24 |
| OND-935/2B | ~14”(~350) | 110/220~ | 50-60 | 4880 | 350/560 | 3.5 | 600 | 21/24 | 104*38*24 |
| OND-935/2BE | ~14”(~350) | 110/220~ | 50-60 | 4880 | 100-350/560 | 3.5 | 600 | 21/24 | 104*38*24 |
